Product description
Graphite Rotor And Wheel For Aluminum Melt Treatment
Graphite Rotor & Graphite Wheel
Graphite rotor and graphite wheel are key consumable parts for aluminum melt stirring, refining and degassing equipment. They are suitable for high-temperature molten aluminum working conditions and help support stable gas dispersion, melt circulation and furnace-side treatment performance.
Available Product Types
✓
Graphite rotor shaft and matching graphite wheel for aluminum melt processing.
✓
Graphite wheel model: Φ200×85, with similar models Φ220×85 and Φ250×85.
✓
Commonly known as double-layer bread type graphite wheel.
✓
Can be customized according to drawing, sample or equipment requirements.
Φ200×85
Main graphite wheel size model for matching rotor systems.
Φ220×85
Similar graphite wheel size for equipment selection.
Φ250×85
Larger matching graphite wheel model for aluminum melt treatment.
Graphite
High-temperature consumable material for molten aluminum operation.
Technical Drawing
Rotor Shaft And Graphite Wheel Structure Reference
The following technical drawing is displayed in a full-width single row. It shows the graphite rotor shaft structure, graphite wheel profile, section view and key dimensional reference for product matching and customized production.
Technical drawing reference for graphite rotor and graphite wheel. The image is displayed as one full-width row for clearer structure viewing.
Product Overview
Graphite Consumables For Aluminum Refining And Degassing
Graphite rotors and graphite wheels are widely used in aluminum melt refining equipment, rotary degassing units, aluminum melt stirring machines and furnace-side purification systems. They help disperse gas, promote melt movement and improve treatment stability before casting.
Graphite Rotor System
The graphite rotor system is used to rotate and drive the working graphite wheel in molten aluminum. It supports gas dispersion and melt circulation during refining and degassing operation.
Suitable for rotary degassing and aluminum melt treatment equipment.
Used in high-temperature molten aluminum working environments.
Can be matched with different graphite wheel models.
Graphite Wheel Component
The graphite wheel is a key working part installed on the rotor system. According to customer information, the Φ200×85 graphite wheel is also commonly called a double-layer bread type, and similar models include Φ220×85 and Φ250×85.
Main model: Φ200×85 graphite wheel.
Similar models: Φ220×85 and Φ250×85.
Suitable for replacement, maintenance and custom matching.
Product Models
Graphite Wheel Size Options
The symbol and numbers before the product name represent the product size model. Selection should be based on rotor shaft connection, equipment model, furnace capacity and actual working conditions.
Φ200×85
Graphite Wheel
Main graphite wheel model. Commonly used for aluminum melt stirring, refining and rotor system matching.
Φ220×85
Similar Model
Similar size graphite wheel for customers requiring a larger diameter while keeping the same thickness.
Φ250×85
Similar Model
Larger graphite wheel model suitable for matching specific aluminum melt treatment equipment structures.
Structure Type
Double-Layer Bread Type Graphite Wheel
Double-Layer
Common Structure Name
The Φ200×85 graphite wheel is commonly referred to as a double-layer bread type graphite wheel.
Rotor Matching
Assembly Application
Designed to work with graphite rotor shafts for aluminum melt stirring, refining and degassing.
Customizable
Size And Structure Support
Matching production can be arranged according to technical drawing, existing sample or equipment model.
Core Advantages
Reliable Performance For Molten Aluminum Treatment
Heat Resistance
Graphite material is suitable for high-temperature molten aluminum working environments.
Stable Rotation
Supports stable rotor operation during aluminum melt stirring, refining and degassing.
Gas Dispersion
Helps disperse refining gas and promote melt circulation during molten aluminum treatment.
Easy Replacement
Suitable for routine maintenance, spare parts stock and consumable replacement.
Applications
Suitable For Aluminum Melt Processing Equipment
Graphite rotor and graphite wheel assemblies are suitable for aluminum alloy melting, refining, degassing, stirring, casting preparation and foundry maintenance applications.
Rotary Degassing Unit
Used as key graphite consumables for molten aluminum degassing operation.
Aluminum Melt Stirring Machine
Supports molten aluminum circulation, mixing and furnace-side treatment.
Aluminum Alloy Refining
Helps improve refining stability before casting, transfer or further processing.
Casting Preparation
Suitable for melt preparation before gravity casting, low pressure casting or die casting.
Foundry Maintenance
Used for routine replacement of graphite consumables in aluminum foundry workshops.
Customized Equipment
Can be matched for different rotor shafts, furnace layouts and equipment structures.
Selection Process
Easy Matching For Rotor And Wheel Replacement
01
Confirm Equipment Type
Confirm whether the product is used for degassing equipment, stirring machines or customized melt treatment systems.
02
Select Wheel Model
Choose Φ200×85, Φ220×85 or Φ250×85 according to actual installation and working requirements.
03
Check Shaft Connection
Confirm thread, shaft diameter, fixing method and rotor assembly structure before production.
04
Install And Replace
Install correctly and replace according to wear condition, production schedule and process requirements.
Custom Graphite Rotor And Wheel Matching Available
Graphite rotor and graphite wheel dimensions may vary according to machine structure, shaft connection, furnace depth and aluminum melt treatment process. Matching production can be provided based on drawings, existing samples or equipment models.
Drawing Production
Manufacture according to technical drawings, dimensions and installation requirements.
Sample Matching
Existing rotor or graphite wheel samples can be used for accurate product matching.
Model Selection
Available models include Φ200×85, Φ220×85 and Φ250×85 graphite wheels.
Batch Supply
Suitable for regular replacement, foundry consumable stock and equipment maintenance.
Need Graphite Rotor And Graphite Wheel Matching?
Provide the product model, equipment type, drawing or sample, and we can help match graphite rotors and graphite wheels for aluminum melt stirring, refining, degassing and foundry production applications.
